Tata Intra V10 Specifications Big on technology, performance, productivity and profits. Big on everything that your business needs. A compact truck that’s designed for the ones who think big and dream big. With the TATA INTRA, you will make the big move that will make your business grow even bigger
Download Specifications
SPECIFICATIONS
INTRA V10 NAC
ENGINE
Engine Type
Common Rail Direct Engine
ENGINE CAPACITY
800 cc
Engine Power
40 HP @ 3750 RPM
Max Torque
96 Nm @ 1750-2000 RPM
Max. speed
80 Kmph
Max. gradeability at rated GVW
45%
DRIVELINE
GEARBOX
Manual, 5-Forward 1-Reverse
CLUTCH
Single plate dry friction diaphragm type
Steering and Brakes
Steering
Hydraulic Power assisted Steering
Front Brakes Disc brakes
Rear Brakes
Drum brakes
SUSPENSION
Front Suspension
Semi-elliptical leaf spring
Rear Suspension
Semi-elliptical leaf spring
DIMENSIONS
Wheelbase (mm)
2250
Overall Length (mm)
4282
Overall Width (mm)
1639
Overall Height (mm)
1921 (Unladen)
Ground Clearance (mm)
175
Load body
Pickup type, Hinged rear tailgate
LxWxH (mm)
2450x1540x400
Turning Radius (mm)
4750
WEIGHT
GVW (kg)
2110
Kerb Weight (kg)
1110
TYRE
165 R14 LT 8PR (Tubeless)
FUEL TANK (L)
35L
Ventilation
NAC
